Hosted Payment Page

The Hosted Payment Page is a fully managed, branded checkout page that you can present at checkout. Creating a Payment Request with the hostedPaymentPage node, will generate a hosted page link that displays your logo, line items, adjustments, and handles the payment flow end-to-end.

How It Works

1. Create a Payment Request with the hostedPaymentPage node included.
2. Direct your customer to the hosted URL returned in the response.
3. The customer completes payment on the branded page.
4. Based on the resultPage configuration, the customer sees a hosted result page, or is redirected to your site.
5. Receive the final payment result via webhooks or query the Payment Request result using the resource Id.

Configuration

Creating a hostedPaymentPage using the Payment Request is as follows:

{
    "reference": "INV-2026-042",
    "payment": {
        "amount": 5500,
        "currencyCode": "AUD",
        "description": "Order #42 - 2x Widget Pro"
    },
    "paymentMethods": [
        "card",
        "google_pay"
    ],
    "hostedPaymentPage": {
        "merchantName": "Acme Store",
        "redirectUrl": "https://merchant.example.com/thank-you",
        "resultPage": "show",
        "lineItems": [
            {
                "title": "Widget Pro",
                "image": "https://merchant.example.com/images/widget.png",
                "amount": 2500,
                "quantity": 2,
                "modifier": "each"
            }
        ],
        "adjustments": [
            {
                "title": "Postage",
                "order": 1,
                "amount": 500,
                "adjustmentType": "shipping"
            }
        ]
    }
}

Properties

HostedPaymentPage

Property	Type	Required	Description
merchantName	string	No	The merchant name displayed on the hosted page. Max 140 characters. Defaults to the merchant name configured during onboarding if not provided.
logo	string	Yes	Base64-encoded image to display as the merchant logo. Use PNG, SVG, or WebP image formats only. Maximum size 10KB.
redirectUrl	string	No	URL to redirect the customer to after payment. Required when resultPage is redirect. Optional when resultPage is show. Must be a valid URL.
resultPage	string	No	Controls what happens after payment completes. Default is show. See Result Page Behaviour.
lineItems	array	No	List of line items to display in the payment summary. Maximum 50 items.
adjustments	array	No	List of adjustments (discounts, shipping, tax) applied to the order. Maximum 10 items.

LineItem

Property	Type	Required	Description
title	string	Yes	Display name of the line item. Max 50 characters.
image	string	No	HTTPS URL of an image for the line item. Same format restrictions as logo (Use PNG, SVG, or WebP image formats only.). Maximum size 10KB.
amount	integer	Yes	Unit price in cents (e.g. 1000 = $10.00). Must be >= 0.
quantity	float	No	Quantity of this item. Must be > 0. Supports up to 3 decimal places (e.g. 1.5, 0.750). Defaults to 1.
modifier	string	No	Unit label displayed alongside the quantity (e.g. “each”, “kg”). Max 50 characters.

Adjustment

Property	Type	Required	Description
title	string	Yes	Display name of the adjustment. Max 30 characters.
order	integer	No	Display order of this adjustment. If provided for one adjustment, it must be provided for all. Must be >= 0. No duplicate values allowed.
amount	integer	Yes	Adjustment amount in cents. Can be negative (e.g. -1000 for a $10.00 discount), zero, or positive (e.g. 500 for a $5.00 shipping fee).
adjustmentType	string	Yes	The type of adjustment. Defaults to other. See Adjustment Types.

Adjustment Types

Value	Description
other	General adjustment (default)
discount	A discount applied to the order
shipping	A shipping fee
tax	Tax applied to the order

Result Page Behaviour

The resultPage property controls what happens after the customer completes (or fails) a payment:

Value	Behaviour	redirectUrl required?
show	Displays the Hosted Payment Page result page with payment outcome.	No (optional — if provided, a “Return to merchant” link is shown)
redirect	Redirects the customer to redirectUrl.	Yes
none	No action after payment.	No

Logo and Image Requirements

• Line item image URLs must be valid HTTPS URLs. Maximum size 10KB.
• Use PNG, SVG, or WebP image formats only.

Validation Rules Summary

Important: When line items and adjustments are provided, the sum of each line item’s amount × quantity plus the sum of all adjustments must equal the payment.amount of the Payment Request.

Rule	Constraint
Line items and adjustments total must equal payment.amount	Sum of (amount × quantity) across all line items plus sum of all adjustments
Maximum line items	50
Maximum adjustments	10
Merchant name length	Max 140 characters
Line item title length	Max 50 characters
Line item modifier length	Max 50 characters
Adjustment title length	Max 30 characters
Adjustment order	Optional, must be >= 0, with no duplicates
Line item quantity	Must be > 0, max 3 decimal places
redirectUrl required when resultPage = redirect	Yes
